What's Yer Air Setup?

I got (4) 1/2" SMCs, I reduce my fill speed with mini ball valves, drilled out plugs to the perfect speed for dumps.. (4) Thomas 315s, I NEED NEW COMPRESSORS BAD.. probably goin with (2) 460s. 12 Gallon tank, 1/2" lines, dual needle KP, single needle KP gauge, firestone bags up front.. contitech in the rear.

I have a 5 gallon air tank, 8- 1/2" E-Air valves,7 switch clear AVS controller, Viair 380 compressor, Optima yellow top under bed along with compressor and all valves.

4-3/8" 250psi e-air valves
1/2" line
firestone 2500's in front
firestone 2600's in rear
1 5 gallon tank
viar 380c compressor
and 1/2" line and 3/8" vavles is perfect speed slower than 1/2" valves faster than 3/8" line

Edited: 10/9/2005 3:27:44 PM by lascrew

* 8 GC valves (recently installed by IF)* KP Components 4-link w/cantilever* Custom fabricated Watts-link designed and installed by Totally Polished* DJM upper & lower control arms*

two 3 gallon tanks.eight 3/8 gc's (the other 4 are under the tanks).two viair 450's (which are way too damn slow), and slam bags.i sure wish i had room for two oasis's.

2 viar 380s, 4 blitzluft valves, 1/2 inch line, airlift bags, 1 5 gallon tank, 1 dual needle viar gauge, 1 extra 9 gallon tank.

I've got a valve manifold from aim with 4 300 psi 3 position valves on it ,a 5 gal tank and blowjax 3/4 hp compressor.Couldn't be happier with the valves.It makes for a clean setup

Edited: 10/31/2005 12:12:32 AM by sadexcuse4s10

airlift bags, viair compressor, 5 gallon tank, 2 3/8" GC 450 ups and 2 3/8" Sirai dumps, 1/2" airline, 2 switches on the dash and lighted gauges ran to the dimmer switch

suicidedoors cups & rear bridge, aim spindles, 2 link built by me

all that valve/tank/compressor shit is under the bed where it belongs

get ya some Mac Daddy air valves. these fuckers are the shit. first valves actually designed for the air ride market and not the industrial market then crossed over.

8 3/8 sirai valves, 1/2 line, viair 550 compressor, 1 5 gallon tank with water trap,
2 firestone 2500's and 2 EAI cans.
Will soon add nitrogen/scuba bottle and hardline.
